A gas measuring instrument using the principle of non spectral infrared absorption. Designed for measuring the concentration of HC and CO gases in motor vehicle gasoline engine exhaust emissions. The instrument adopts advanced foreign technology, import key components assembled, with automatic zero adjustment, high brightness digital display, automatic data processing, gas blocking, automatic alarm and other advanced functions. Equipped with analog output interface and RS-232C digital serial communication interface. The utility model has the advantages of convenient operation, accurate measurement, reliable work, etc., and is a new exhaust gas analyzer. We are a professional to provide a full range of PCB copy board, circuit board (clone), chip decryption, PCB design, PCB production and processing services Kemaolong limited company, please call us for consultation and negotiation!

Main technical parameters

The measuring range:

HC:0 ~ 10000 * 10-6 (PPM) Vol

CO:0 ~ 10 * 10-2 (%) Vol

The indication error:

HC: + 30 ppm Vol (absolute error) or

+ 10% (relative error)

CO: + 0.2% Vol (absolute error) or

+ 10% (relative error)

The response time: less than 10s

The preheating time: 30min

The power supply: AC220V + 10% 50Hz + 1Hz

- weight: 12kg

- dimensions:

320mm (width) * 200mm (high) * 540mm (deep)
